🪵 Conquer Massive Wood Piles With Commercial-Grade 25-Ton Splitting Power
SuperHandy GUO096 25-Ton Gas Powered Log Splitter | 7HP 209cc Engine | Horizontal & Vertical Operation
Built for serious firewood production, the SuperHandy GUO096 25-Ton Log Splitter combines a powerful 7HP 209cc gas engine, professional-grade hydraulic system, and massive 25-ton splitting force to tackle hardwoods, knotty rounds, and oversized logs with confidence.
Whether you're preparing winter firewood, maintaining acreage, running a farm, or processing large wood piles, this heavy-duty splitter delivers the power, speed, and reliability needed for demanding jobs.
🔥 Why Property Owners Choose The GUO096
⚡ Massive 25-Ton Splitting Force
Generate up to 25 tons of hydraulic splitting power to break through dense hardwoods and large-diameter logs with less effort.
🪓 Split Larger Logs Faster
Handles logs up to:
-
20.5 Inches Long
-
16 Inches Diameter (Horizontal)
-
24 Inches Diameter (Vertical)
⏱️ Fast 7.5-Second Cycle Time
The high-performance hydraulic system resets quickly, helping you split more wood in less time.
🚜 True Horizontal & Vertical Operation
Switch between horizontal and vertical modes to handle heavy rounds without lifting oversized logs.
🌲 Built For Serious Firewood Production
Perfect for farms, acreage properties, homesteads, ranches, workshops, and seasonal wood processing.
⚙️ Key Features
⛽ Powerful 7HP 209cc Gas Engine
The heavy-duty 209cc 4-stroke gas engine delivers reliable power to the hydraulic system for consistent splitting performance.
Why It Matters:
✔ No electrical cords required
✔ Excellent outdoor performance
✔ Reliable all-day operation
✔ Built for demanding workloads
🪵 25-Ton Hydraulic Splitting System
Powered by a professional-grade hydraulic setup featuring a 2-Stage Bucher Hydraulic Gear Pump.
Why It Matters:
✔ Maximum splitting force
✔ Faster wood processing
✔ Consistent hydraulic pressure
✔ Handles dense hardwood species
⚡ Rapid Auto Return System
The hydraulic ram automatically resets after each split with a fast 7.5-second cycle time.
Why It Matters:
✔ Increased productivity
✔ Less downtime
✔ Faster firewood production
🔄 Horizontal & Vertical Splitting Modes
Operate horizontally for standard logs or vertically for oversized rounds.
Why It Matters:
✔ Easier handling of large logs
✔ Reduced lifting strain
✔ Greater versatility
🏗️ Heavy-Duty Steel Beam Construction
Built with a reinforced steel frame, durable wedge system, and industrial-grade components.
Why It Matters:
✔ Long-term durability
✔ Stable operation
✔ Professional-grade reliability
🛞 10-Inch Transport Wheels
Features durable 10-inch polyurethane transport wheels for easier movement around your property.
Why It Matters:
✔ Better portability
✔ Easier transportation
✔ Improved maneuverability
🚀 Performance Overview
Engine Performance
-
Engine Type: 209cc 4-Stroke Gas Engine
-
Horsepower: 7HP
-
Fuel Type: Gasoline
-
Fuel Tank Capacity: 0.74 Gallons
-
Engine Oil Capacity: 0.145 Gallons (0.55L)
-
Recommended Oil: SAE 10W-30
Splitting Performance
-
Splitting Force: 25 Tons
-
Maximum Horizontal Log Diameter: 16 Inches
-
Maximum Vertical Log Diameter: 24 Inches
-
Maximum Log Length: 20.5 Inches
-
Cycle Time: 7.5 Seconds
Hydraulic System
-
Hydraulic Pump: 2-Stage Bucher Hydraulic Gear Pump
-
Hydraulic Oil Type: AW32 Hydraulic Oil
-
Rapid Auto Return Function
Terrain Capability
Designed for:
-
Farms
-
Ranches
-
Acreage properties
-
Wood yards
-
Outdoor firewood processing
-
Remote locations
📊 Full Technical Specifications
| Specification | Details |
|---|---|
| Product Name | SuperHandy Gas Powered Log Splitter |
| Model | GUO096 |
| Splitting Force | 25 Tons |
| Engine Type | 4-Stroke Gas Engine |
| Engine Displacement | 209cc |
| Engine Power | 7HP |
| Hydraulic Pump | 2-Stage Bucher Hydraulic Gear Pump |
| Cycle Time | 7.5 Seconds |
| Maximum Log Length | 20.5 Inches |
| Max Horizontal Log Diameter | 16 Inches |
| Max Vertical Log Diameter | 24 Inches |
| Operating Modes | Horizontal & Vertical |
| Wheel Size | 10 Inches |
| Wheel Type | Polyurethane Transport Wheels |
| Fuel Tank Capacity | 0.74 Gallons |
| Engine Oil Capacity | 0.145 Gallons (0.55L) |
| Recommended Engine Oil | SAE 10W-30 |
| Recommended Hydraulic Oil | AW32 |
| Frame Material | Heavy-Duty Steel |
| Product Weight | 196–253 lbs (depending on configuration source) |
| Overall Dimensions | 50.63" x 26.61" x 42.89" |
| Low Oil Shutoff | Yes |
| Emissions Compliance | EPA & CARB Compliant |
| Start Type | Recoil Pull Start |
⚔️ Comparison Table
| Feature | SuperHandy GUO096 | Champion 27-Ton Splitter | Boss Industrial GD20T24 |
|---|---|---|---|
| Splitting Force | ✅ 25 Tons | 27 Tons | 20 Tons |
| Engine Size | ✅ 209cc 7HP | 224cc | 196cc |
| Horizontal & Vertical Operation | ✅ Yes | Yes | No |
| Cycle Time | ✅ 7.5 Seconds | Slower | Slower |
| Hydraulic Pump | ✅ 2-Stage Bucher Pump | Standard Pump | Standard Pump |
| Max Vertical Diameter | ✅ 24" | Lower | Not Available |
| Wheel Size | ✅ 10" Poly Wheels | Standard Wheels | Standard Wheels |
| EPA/CARB Compliance | ✅ Yes | Yes | Varies |
Why Customers Choose SuperHandy
✔ Massive 25-ton splitting force
✔ Fast 7.5-second cycle time
✔ Horizontal & vertical operation
✔ Reliable 7HP 209cc engine
✔ Commercial-grade hydraulic system
✔ Excellent portability
📦 What's Included In The Box?
-
SuperHandy GUO096 Log Splitter
-
7HP 209cc Gas Engine
-
25-Ton Hydraulic Ram System
-
2-Stage Bucher Hydraulic Pump
-
Heavy-Duty Steel Splitting Wedge
-
10-Inch Polyurethane Wheels
-
Hardware Kit
-
User Manual
🛡️ Shop With Confidence
🔒 Secure Checkout
Encrypted payment processing helps protect your information.
🚚 Fast Shipping
Carefully packaged and shipped with tracking information.
🧰 Quality Inspection
Every unit is inspected before shipment to help ensure dependable performance.
📞 Dedicated Customer Support
Responsive assistance for setup, maintenance, and troubleshooting.
🏆 Warranty Protection
Backed by manufacturer warranty coverage where applicable.
❓ Frequently Asked Questions
Does this splitter require electricity?
No. It operates using a 7HP 209cc gas engine.
How much splitting force does it generate?
The hydraulic system produces up to 25 tons of splitting force.
What size logs can it handle?
Up to 20.5 inches long, 16 inches diameter horizontally, and 24 inches diameter vertically.
What is the cycle time?
The hydraulic ram resets in approximately 7.5 seconds.
Can it split hardwood?
Yes. It's designed for hardwoods, softwoods, knotty rounds, and large firewood logs.
Does it operate vertically?
Yes. It supports both horizontal and vertical splitting modes.
What hydraulic oil should be used?
AW32 Hydraulic Oil is recommended.
Is assembly required?
Some assembly is required after delivery.
🌲 Built For Serious Firewood Production
The SuperHandy GUO096 combines a powerful 7HP 209cc gas engine, professional-grade 2-stage hydraulic pump, massive 25-ton splitting force, and versatile horizontal/vertical operation into one heavy-duty firewood processing machine.
From large acreage maintenance to winter firewood preparation, this splitter is built to handle demanding workloads with speed, consistency, and confidence.
