Lightweight Carbon. Intelligent Power. Built to Ride.
Meet the Urtopia Carbon 1 Pro E-Bike — a premium carbon-fiber electric bike designed for riders who want a refined commute without the bulk of a conventional e-bike. With a 350W rear-hub motor, 45Nm of torque, 36V 9.8Ah Samsung Li-ion battery, up to 81 miles of pedal-assist range and a 28 mph unlocked top speed, it brings smart technology and lightweight performance into one clean package.
Designed for Riders Who Expect More
The Carbon 1 Pro is made for the modern rider who values low weight, responsive pedal assistance, long-distance capability and premium design. Its Toray carbon-fiber frame and fork keep the bike exceptionally light, while the rear-hub motor and torque sensor create a natural pedal-assisted riding experience for city streets, bike paths and light gravel.
- 37 lbs lightweight construction for easier handling and transport.
- 350W rated / 500W peak rear-hub motor with 45Nm maximum torque.
- 36V 9.8Ah Samsung Li-ion battery with 352.8Wh capacity.
- Removable battery for convenient charging away from the bike.
- Up to 81 miles of pedal-assist range under specified ECO testing conditions.
- 20 mph default / 28 mph unlocked top speed configuration.
- TEKTRO 2-piston hydraulic disc brakes for controlled stopping.
- 700C x 40mm Kenda tires with compatibility up to 45mm width.
- 4 levels of pedal assist with torque sensing for responsive assistance.
- GPS, 4G, Bluetooth, navigation and fingerprint unlock through the Smartbar system.
Why Riders Love the Carbon 1 Pro
Carbon-Fiber Lightweight Design
The carbon-fiber frame and carbon-fiber fork create a refined, lightweight platform. The published bike weight is 41 lbs (18.6 kg), while the listed net weight is 38 lbs (17.4 kg) with battery and 33 lbs (15.2 kg) without battery.
Responsive 350W Motor
The rear-hub motor delivers 350W rated power, 500W peak power and 45Nm maximum torque. Its compact inner-rotor design is intended to provide a quiet, quick-response ride for urban and light off-road use.
Samsung Removable Battery
A 36V 9.8Ah Samsung Li-ion battery provides 352.8Wh of energy. It is removable and UL 2271 certified, with a listed 2.5-hour charging time using the 36V 4A fast charger.
Smartbar Intelligence
The integrated Smartbar combines on-board navigation, fingerprint unlock, AI assistant, voice control, Bluetooth speaker and OTA firmware updates. Connectivity includes 4G eSIM, GPS and Bluetooth.
Natural Torque-Sensing Assist
A torque sensor, accelerometer and gyroscope work with four pedal-assist levels. Instead of relying on a throttle, the Carbon 1 Pro responds to your pedaling input for a more bicycle-like riding feel.
700C Gravel-Ready Tires
The Kenda 700C x 40mm tires balance efficiency, stability and comfort. The frame and fork can accommodate tires up to 45mm, making the Carbon 1 Pro suitable for pavement, bike paths, gravel and light mixed-surface riding.
Hydraulic Disc Braking
TEKTRO 2-piston hydraulic disc brakes provide controlled braking for everyday commuting and mixed-surface riding, complementing the bike's 700C wheels and lightweight carbon platform.
Integrated Visibility
The front system uses an integrated StVZO headlight rated at 90 lumens. The rear uses a dry-battery tail light; the optional ARES light is a separate upgrade.
Full Technical Specifications
| Model | Urtopia Carbon 1 Pro E-Bike |
|---|---|
| Ideal Use | Commuter |
| Motor Configuration | Single rear-hub motor |
| Motor Rated Power | 350W |
| Motor Peak Power | 500W |
| Motor Maximum Torque | 45Nm |
| Motor Type | Rear hub, inner-rotor design |
| Battery Voltage | 36V |
| Battery Capacity | 9.8Ah |
| Battery Energy | 352.8Wh |
| Battery Type | Samsung Li-ion |
| Battery Certification | UL 2271 Certified |
| Battery | Removable |
| External Battery | No |
| Pedal Assist | 4 levels |
| Throttle | No |
| Class | Class 1 as listed on the product page; 28 mph operation is available upon unlock and may be subject to local requirements. |
| Top Speed | 20 mph by default; 28 mph upon unlock |
| Maximum Pedal-Assist Range | Up to 81 miles under the stated test conditions |
| Range Test Conditions | 180 lb rider, ECO mode, flat roads, pedal assist only, no throttle |
| Payload Capacity | 240 lbs total payload limit |
| Recommended Rider Height | 5'3"–6'5", depending on frame size |
| Small Frame | 5'3"–5'9" |
| Medium Frame | 5'7"–6'1" |
| Large Frame | 5'11"–6'5" |
| Frame Material | Carbon fiber; Toray carbon fiber construction |
| Fork / Suspension | Carbon-fiber rigid fork; no suspension system is specified on the product page |
| Brakes | TEKTRO 2-piston hydraulic disc brakes |
| Wheels / Tires | Kenda 700C x 40mm tires; maximum compatible tire width 45mm |
| Front Tire | 700C x 40mm |
| Rear Tire | 700C x 40mm |
| Water Resistance | IP65 |
| Charger | 36V 4A fast charger |
| Charging Time | 2.5 hours |
| Display | LED dot-matrix, anti-glare |
| Sensors | Torque sensor, accelerometer and gyroscope |
| Lighting | Front integrated StVZO headlight, 90 lm; rear dry-battery tail light; ARES rear light optional |
| Controller Specifications | The current product page does not publish a separate controller model, rated current or controller wattage specification. |
| Bike Weight | 41 lbs (18.6 kg) |
| Net Weight With Battery | 38 lbs (17.4 kg) |
| Net Weight Without Battery | 33 lbs (15.2 kg) |
| Weight Tolerance | Published weights have a tolerance of less than 5% |
| Shipping Weight | Not published on the current product page |
| Folding | No |
| Frame Style | Step-over |
| Chainring | 44T |
| Crankset | Aluminum alloy, 170mm |
| Cassette | 11T–40T, 8-speed |
| Chain | Shimano 8-speed |
| Rear Derailleur | Shimano ACERA 8-speed |
| Shift Lever | 8-speed trigger |
| Pedals | 9/16" alloy platform |
| Handlebar | Aluminum, 28.6mm clamp, 720mm wide |
| Stem | Height adjustable: 0 / 15 / 30mm |
| Seat Post | Aluminum alloy, 31.6mm clamp; 100mm for M/L, 80mm for S |
| Saddle | COINLLI Saddle, 268 x 173 x 71mm |
| Grips | Durable ergonomic lockable grips |
| Smartbar | On-board navigation, fingerprint unlock, AI assistant, voice control, Bluetooth speaker, OTA updates, IP65 |
| Connectivity | eSIM with 4G, GPS and Bluetooth |
| Theft Protection | Movement alarm, Electronic Fence, Find My Bike live GPS tracking and beep |
| App | Urtopia app for iOS and Android |
| Connect Service | eSIM/connect service renewal through the Urtopia app |
| Standover Height | 779mm (31") for the listed Small geometry |
| Adjustable Seat Range | 80mm (3") for the listed Small geometry |
| Handlebar Grip Height | 995–1025mm (39"–40") for the listed Small geometry |
| Seat Tube Length | 421mm (17") for the listed Small geometry |
| Wheelbase | 1065mm (42") for the listed Small geometry |
| Overall Length | 1766mm (70") for the listed Small geometry |
| Wheel Diameter | 702mm (28") |
| Effective Top Tube | 594mm (23") |
| Head Tube Length | 152mm (6") |
| Headset Height | 90–120mm (4"–5") |
Performance That Feels Like a Bicycle — With More Intelligence
Power & Range
The Carbon 1 Pro combines a 350W rated rear-hub motor with 500W peak power and 45Nm maximum torque. Its 36V 9.8Ah, 352.8Wh Samsung Li-ion battery is removable and can be charged in approximately 2.5 hours using the supplied 36V 4A fast charger.
The manufacturer lists up to 81 miles of pedal-assist range when tested with a 180 lb rider in ECO mode on flat roads using pedal assist only. Actual range will vary with rider weight, terrain, temperature, speed, tire pressure and assist level.
Key Performance Metrics
Terrain & Hills
The Carbon 1 Pro is designed around urban riding, commuting, bike paths, gravel and light off-road surfaces. Its 45Nm rear-hub motor is responsive and lightweight, but the manufacturer specifically notes that mid-drive systems are better suited to very steep climbs. A maximum hill grade is not published, so no unsupported climbing percentage is claimed here.
Riding Comfort
Comfort comes from the lightweight carbon platform, 700C x 40mm tires, ergonomic lockable grips, adjustable seat post and a Smartbar stem adjustable through 0 / 15 / 30mm. The fork is rigid carbon fiber, not a suspension fork, so the bike favors efficient road and gravel handling over suspension-focused trail riding.
How It Compares
| Model / Category | Urtopia Carbon 1 Pro | Specialized Turbo Vado SL 4.0 EQ | Trek FX+ 7 | Generic Commuter Scooter |
|---|---|---|---|---|
| Power | 350W rated / 500W peak | Specialized SL 1.1 lightweight motor | 250W continuous / 300W maximum | Varies by model |
| Torque | 45Nm | 35Nm | 50Nm | Varies by model |
| Battery | 36V 9.8Ah / 352.8Wh Samsung Li-ion, removable | 320Wh integrated | 360Wh | Usually integrated or removable depending on model |
| Range | Up to 81 miles under specified ECO test conditions | Up to 80 miles with compatible range extender | Up to 50 miles; up to 75 miles with range extender | Varies significantly |
| Weight | 41 lbs listed bike weight | Lightweight aluminum platform | Approximately 40 lbs | Often heavier and bulkier than a bicycle |
| Smart Features | 4G, GPS, navigation, AI assistant, voice control, fingerprint unlock, Bluetooth, theft tracking | Integrated Specialized electronics and Bluetooth/ANT+ interface | Trek Central connectivity and ride planning | Depends on model |
| Why Choose Carbon 1 Pro? | A distinctive combination of carbon-fiber construction, removable Samsung battery, 45Nm rear-hub power, 81-mile claimed ECO range and advanced Smartbar technology. | Strong established lightweight commuter alternative | Higher torque and a polished lightweight commuter platform | More upright utility-focused format, but typically less bicycle-like in handling |
Built for Confidence
🔒 Secure Checkout
Complete your purchase through a secure online checkout designed to protect payment information.
🚚 Free Shipping
Free shipping is advertised for the Carbon 1 Pro. The manufacturer lists delivery within 5 business days for the product.
🧰 Quality Support
Urtopia advertises real-person support, local service partners and technical assistance.
🛡️ Warranty
The manufacturer advertises a 2-year warranty on all e-bikes. Warranty coverage is subject to the applicable warranty terms.
↩️ 14-Day Trial
The manufacturer advertises a 14-day trial/return period. Review applicable return conditions before ordering.
🧪 Safety Certified
The battery is listed as UL 2271 certified, and the product page also highlights UL 2849 safety certification.
💵 No Sales Tax
No Sales Tax is offered through this store where applicable. Final checkout terms should be reviewed before purchase.
📦 Product Inspection
Inspect the package and bike for visible shipping damage immediately after delivery and document any issue before riding.
What's In The Box
The current manufacturer product page does not publish a complete, line-by-line carton inventory. To avoid inventing accessories, the following are the components explicitly associated with the Carbon 1 Pro specification:
- Carbon 1 Pro E-Bike
- 36V 9.8Ah / 352.8Wh removable Samsung Li-ion battery
- 36V 4A fast charger
- 9/16" alloy platform pedals
- Integrated Smartbar system
- Integrated front StVZO headlight
- Rear tail light with dry battery
Carbon 1 Pro FAQ
How long does the Carbon 1 Pro battery take to charge?
The included fast charger is rated at 36V 4A, and the manufacturer lists a 2.5-hour charging time for the 352.8Wh Samsung Li-ion battery.
What is the top speed of the Carbon 1 Pro?
The listed default top speed is 20 mph. The product page states that the bike can reach 28 mph upon unlock. Speed-class and road-use requirements can vary by jurisdiction.
How far can the Carbon 1 Pro travel on one charge?
The manufacturer lists up to 81 miles of pedal-assist range. That figure was tested with a 180 lb rider in ECO mode on flat roads using pedal assist only with no throttle. Real-world range will vary.
What rider height is the Carbon 1 Pro designed for?
The published range is 5'3" to 6'5". Small is listed for 5'3"–5'9", Medium for 5'7"–6'1", and Large for 5'11"–6'5".
What is the maximum rider and cargo payload?
The Carbon 1 Pro has a published 240 lb total payload limit. This includes the rider and applicable carried load.
Does the Carbon 1 Pro require assembly?
The current product page does not publish a detailed assembly percentage or assembly-time specification. Follow the supplied owner documentation and have a qualified bicycle technician complete safety-critical adjustments if needed.
Is the Carbon 1 Pro waterproof?
It is listed as IP65 water resistant, meaning it is designed to resist dust and water spray. IP65 should not be interpreted as permission to submerge the bike or battery.
Does it require a driver's license?
The product page lists the bike as Class 1 but also states that 28 mph operation is available upon unlock. E-bike classification, registration and licensing rules vary by location, so riders should verify local regulations before using the unlocked configuration on public roads.
Can the Carbon 1 Pro handle gravel and rough terrain?
Yes, it is designed for city streets, gravel and light off-road riding. The 700C x 40mm tires provide a useful balance of rolling efficiency and stability, with compatibility up to 45mm tire width. The bike uses a rigid carbon fork rather than suspension.
How long will the Samsung battery last?
The product page specifies the 352.8Wh Samsung Li-ion battery and UL 2271 certification but does not publish a guaranteed number of charge cycles or a fixed battery lifespan. Actual lifespan depends on charging habits, storage conditions, temperature, usage and other factors.
Ready for a Smarter Ride?
Choose the Carbon 1 Pro for its carbon-fiber construction, 350W motor, 45Nm torque, removable Samsung battery, up to 81-mile claimed ECO range and intelligent Smartbar technology.
